Streamlit Tutorial

What is Streamlit?

Streamlit is an open-source Python library that makes it easy to create and share beautiful custom web apps for machine learning and data science.

  • To install Streamlit:
pip install streamlit
  • To test it:
import streamlit as st

st.write('Hello World')
  • To run the example:
streamlit run main.py

How streamlit works is that it evaluate your file from top to bottom and render each thing in the order that they appear.

  • Add a text input and rerun the example:
st.text_input('Favorite Movie?')

Using Input Elements

Streamlit provides a lot of different input elements you can use, example:

# this capture the return value into x
x = st.text_input('Favorite Movie?')

st.write(f"Your favorite movie is: {x}")
  • You can create: buttons, sliders and dropdowns, and anything you can expect to find in an interactive app. Example:
is_clicked = st.button("Click Me")
  • Streamlit supports Markdown formatting by default. Example:
import streamlit as st

st.write("## This is a H2 Title!")

st.markdown("*Streamlit* is **really** ***cool***.")
st.markdown('''
    :red[Streamlit] :orange[can] :green[write] :blue[text] :violet[in]
    :gray[pretty] :rainbow[colors] and :blue-background[highlight] text.''')
st.markdown("Here's a bouquet —\
            :tulip::cherry_blossom::rose::hibiscus::sunflower::blossom:")

multi = '''If you end a line with two spaces,
a soft return is used for the next line.

Two (or more) newline characters in a row will result in a hard return.
'''
st.markdown(multi)

Working with Data

  • If you have a CSV file that you want to use as part of your app, this how you can do it (movies.csv contain different movies available on Netflix):
import pandas as pd

data = pd.read_csv("movies.csv")
# This shows the data in a nice table
st.write(data)  # display the data inside the app
  • You can also show your data in a graph:
import numpy as np

# Some random generated data
chart_data = pd.DataFrame(
    np.random.randn(20, 3),
    columns=["a", "b", "c"]
)

st.bar_chart(chart_data)
st.line_chart(chart_data)

Multipage Apps

If your app starts to get too big to fit on a single page, Streamlit also gives you an easy way to create multi-page application.

All you have to do is just structure the project so that you have a directory names pages and then with each page as a file inside that directory. Try this example:

project
|___ main.py
|___ pages
     |___ 1_profile.py
     |___ 2_dashboard.py

Streamlit uses the naming convention and the structure of your directory to figure out how to organize its pages. And you can tell it which order to display the pages by prefixing it with a number.

Loan Repayments App

Streamlit is generally used in building simpler apps that are interactive and heavily focused on working with data or machine learning.

Let’s build a Loan Repayments Calculator to put in practise all of this:

import streamlit as st
import pandas as pd
import matplotlib.pyplot as plt
import math

st.title("Mortgage Repayments Calculator")

st.write("### Input Data")
col1, col2 = st.columns(2)  # Display elements in 2 column using the column component
# Set a default value or minimum/maximum value
home_value = col1.number_input("Home Value", min_value=0, value=500000)
deposit = col1.number_input("Deposit", min_value=0, value=100000)
interest_rate = col2.number_input("Interest Rate (in %)", min_value=0.0, value=5.5)
loan_term = col2.number_input("Loan Term (in years)", min_value=1, value=30)

# Calculate the repayments.
loan_amount = home_value - deposit
monthly_interest_rate = (interest_rate / 100) / 12
number_of_payments = loan_term * 12
monthly_payment = (
    loan_amount
    * (monthly_interest_rate * (1 + monthly_interest_rate) ** number_of_payments)
    / ((1 + monthly_interest_rate) ** number_of_payments - 1)
)

# Display the repayments.
total_payments = monthly_payment * number_of_payments
total_interest = total_payments - loan_amount

st.write("### Repayments")
col1, col2, col3 = st.columns(3)    # Create 3 columns
col1.metric(label="Monthly Repayments", value=f"${monthly_payment:,.2f}")
col2.metric(label="Total Repayments", value=f"${total_payments:,.0f}")
col3.metric(label="Total Interest", value=f"${total_interest:,.0f}")


# Create a data-frame with the payment schedule.
schedule = []
remaining_balance = loan_amount

for i in range(1, number_of_payments + 1):
    interest_payment = remaining_balance * monthly_interest_rate
    principal_payment = monthly_payment - interest_payment
    remaining_balance -= principal_payment
    year = math.ceil(i / 12)  # Calculate the year into the loan
    schedule.append(
        [
            i,
            monthly_payment,
            principal_payment,
            interest_payment,
            remaining_balance,
            year,
        ]
    )

df = pd.DataFrame(
    schedule,
    columns=["Month", "Payment", "Principal", "Interest", "Remaining Balance", "Year"],
)

# Display the data-frame as a chart.
st.write("### Payment Schedule")
payments_df = df[["Year", "Remaining Balance"]].groupby("Year").min()
st.line_chart(payments_df)

Deploying to Streamlit Cloud

To deploy streamlit app, you can use Streamlit Cloud to deploy for free and it will be publicly visible.

  • First, make sure that your app is published to Github because that’s where Streamlit is going to read the source code and then deploy it from.
  • Make sure to put the dependencies in requirements.txt file. You can use the following command to create it (you have to be in a virtual environment):
pip freeze > requirements.txt
  • Then go back to your local version of the app, and click the Deploy button in the top corner. And choose to deploy to Streamlit Community Cloud for free. Then click Deploy.

By Wahid Hamdi
